Easy Loading And Unloading European Wire Rope Hoist

Time：2023-11-29

Brief Explanation :

With the development of the social economy, more and more stage electric hoists are emerging.

Category : W12 Stage Electric Hoist

Get a Quote

Product Details

With the development of the social economy, more and more stage electric hoists are emerging. So what are the components of stage electric hoists?

1、 Hook component

Hook, cable board, frame, cross pin, cruise ship

2、 Body components

Cover: Cover, nut, gasket.

Hulu head: gear, three plates, lifting wheel, guide wheel, baffle (chain splitter), support rod.

Planetary reducer: box, planetary carrier, planetary gear, flat key, spring retaining ring.

Motor: motor, sun gear, flat key, retaining ring

3、 Chain

Using 80 level large Baotou chain

4、 Lower hook component

Hook, cable tray, cruise ship, lower frame

The group crane electric hoist is driven by an electric motor to drive planetary gears, which drive a five tooth long shaft through a planetary carrier. The five tooth long shaft drives a plate gear, a four tooth short shaft, and a spline hole gear. In this way, the lifting sprocket installed on the spline hole gear drives the lifting chain, allowing for smooth lifting of heavy objects. The group crane electric hoist is braked by a disc motor under load.
