Electric hoists represent their own machinery, strength, and toughness, while the stage is elegant, flowing, and soft, with conflicts and collisions between the two.
Although the number of stage chain electric hoists used in various evening parties varies, they all have the following commonalities:
Category : W12 Stage Electric Hoist
Get a Quote
Product Details
Although the number of stage chain electric hoists used in various evening parties varies, they all have the following commonalities:
1. Protection level IP56
High strength aluminum alloy shell, die-casting integrated molding, corrosion-resistant, non rusting. High sealing performance, suitable for operation in rain, easy installation, light weight, and good heat dissipation.
2. Multi layer helical gear transmission of gearbox
The gear accuracy level is 6 poles, with quiet and safe operation. The gearbox adopts complete oil valley lubrication, which can achieve lifelong maintenance free after sealing. It has temperature adjustment function and an ultra long service life.
3. High performance motors
Small size, high starting torque, suitable for high-frequency continuous operation, insulation level F pole, equipped with motor overheating protection device.
4. 45 ° chain guide
The newly designed side chain design ensures a quiet and smooth operation of the chain.
5. Clutch
Built in mechanical overload safety clutch to prevent damage to the hoist body and chain caused by overload or impact.
6. Mechanical assisted braking
The coordination between mechanical brakes and magnetic brakes effectively ensures the braking system.
7. Protective devices
When using a 36V low-voltage control and reverse protection device, the control circuit cannot operate when the power line is connected incorrectly.
8. Electromagnetic brake
Independent electromagnetic brake, release immediately after power failure, brake lock up, safe and reliable.
9. Contact type limit
Contact type limit can effectively prevent power outage caused by diagonal chain pulling, thus stopping the operation.
