Solution to poor contact of sliding wires in electric hoists
1、 Due to the fact that electric hoists are generally installed on U-shaped tracks, combined with this feature, steel cables can be arranged above the I-beam in the middle of the track. At the same time, the editor suggests using 10mm steel wire rope or round steel, and using basket bolts to secure the ends.
2、 The sliding ring is two circular rings that are interlocked, and as long as there is a certain margin left, it can prevent the steel cable from scratching and getting stuck; The steering ring is connected to two circular rings by bolts and can rotate freely.
3、 Firstly, place one end of the steering ring on the steel cable, leave the motor lead and fix the rubber sleeve wire to the lower end of the steering ring. Then, thread multiple sliding ring ends onto the steel cable, and fix the rubber sleeve wire in segments to the lower end of the sliding ring. The front end is connected to the motor, which can rotate freely, and the rear end is connected to the power supply.
4、 Under the traction of the motor, the steel cable is pulled in a straight or circular motion with the steering ring as the center.
