Electric hoists represent their own machinery, strength, and toughness, while the stage is elegant, flowing, and soft, with conflicts and collisions between the two.
0.5~2 ton lifting capacity
Category : V7 Stage Electric Series
Get a Quote
Product Details
0.5~2 ton lifting capacity
With upper hook (fixed) or with trolley
Single/Double speed option
Shell: aluminum alloy
Chain: high quality G80
Chain container: canvas / iron
Gear & chain wheel: alloy steel + heat treatment
Hooks: heat forging+heat treatment
Chain diameter: 6.3~11.2mm (as per different capacities)
Motor rotate speed:1440r/min(single speed), 2880/960 r/min(double speed),
Standard chain length: 3m (can be customized)
Power specification:200~690V,50/60HZ,3 Phase
Safe voltage:24V/36V/48V
Button switch:2/4/6/8 buttons option
Insulation grade:F class
Protection class: IP55
Working group:M4
Working temperature: -40ºC ~ +40ºC
OEM acceptable
Customized logo acceptable
Package: plywood case
Warranty: 2 years for mechanical parts, 1 year for electric parts
