Electric hoists represent their own machinery, strength, and toughness, while the stage is elegant, flowing, and soft, with conflicts and collisions between the two.
When performing daily maintenance on the chain hoist, the machine can be immersed in a kerosene tank for a few minutes and shaken a few times. After draining the dirty oil, a few drops of engine oil c
Category : Stage Chain Hoist Series
Get a Quote
Product Details
How to maintain the chain and lever gourd?
When performing daily maintenance on the chain hoist, the machine can be immersed in a kerosene tank for a few minutes and shaken a few times. After draining the dirty oil, a few drops of engine oil can be added inside the movement.
The internal mechanism components of the chain wrench should be cleaned and lubricated according to usage. If there is a lot of accumulated dirt inside the machine, the hoist should be dismantled to prevent the movement from being blocked and affecting its use. After each project is completed, it should be cleaned and maintained once.
After disassembling and cleaning the body parts, they should be installed in their original positions, checked and confirmed to be normal before continuing to be used.
The riveting joint of the chain hoist cannot be disassembled.
When reassembling, the length direction of the clip must be reassembled according to the structural diagram.
Disassembly and maintenance should be carried out by skilled workers with maintenance experience and mechanical knowledge
The reason for the sliding chain of the lifting chain during the process of lifting goods with a chain hoist
The phenomenon of sliding chain in the lifting chain of a chain hoist is generally caused by the brake system failure of the hoist, which can be divided into several situations
1. Friction plate wear leads to
2. Finger snap ring broken
3. Finger spring failure
The hand chain hoist adopts metal composite friction plate technology, which makes the friction plates less prone to friction and provides stable braking effect. There is no need to replace the friction plates. In addition, the hand chain hoist adopts a dual brake design, which ensures more stable braking
